Aluminum shell
High strength aluminum die casting outer shell.Perfect sealed,light weight,good heat dissipation,lP65 protection.
Double electromagnetic brakes
lndependent double electromagnetic brakes.It will lock the brakeimmediately after power source is off.Safe and reliable.
Electric motor
High performance electric motor with overheat protection device,small size,high start-up torque,frequent and continous operation.
Chains
G100 chains made of alloy steel ,8 times safety factor,complianceto EN818-7.
Touch type limit switch
Precise electronic position limit switch.It can adjust electric hoisttravel distance,avoid collision and guarantee its safe operation.overload clutch
Maintence free overload clutch is integrated on the gear shaft.overload protection and anti-collision.
Gear transmission set
Helical gear multi-drive transmission,gears grade 6,safe operation,low noise,oil lubricated,maintainence free.
Lifting sprocket
5 pockets and double sides bearings design,special alloy steelmaterial.low vibration and low wearina.Safe and auiet operation.
Compliancec to germany BGG-D8+ regulation. CE certified.
OPTIONAL ENCODER TO REALIZE DIGITAL CONTROL.
Parameter| MODEL | CAPACITY (kg) | VOLTAGE (V/3P) | LIFTING HEIGHT (m) | CHAIN FALL NO. | LIFTING SPEED (m/min) | POWER (kw) | LOAD CHAIN DIA (mm) | CHAIN NET WEIGHT ( kg/m) | G.W(kg) |
| SU-GP-0.3 C1 | 300 | 220-440 | ≥10 | 1 | 0-30 | 1.9 | 5*15 | 53 | 0.54 |
| SU-GP-0.5 C1 | 500 | 220-440 | ≥10 | 1 | 0-19 | 1.9 | 7.1*21 | 53 | 1.1 |
| SU-GP-0.75 C1 | 750 | 220-440 | ≥10 | 1 | 0-9.5 | 1.9 | 7.1*21 | 53 | 1.1 |
| SU-GP-1.0 C1 | 1000 | 220-440 | ≥10 | 1 | 0-8 | 2.2 | 9*27 | 53 | 1.8 |
Advantages
Hebei Huaige Lifting Machinery Group Co., Ltd. was founded in 1980 and is a light and small lifting machinery manufacturing enterprise rooted in the land of Yanzhao. After 40 years of ups and downs and 20 years of rapid development, it has stood out.
Huaige Group is committed to providing supporting products for lifting machinery equipment, serving industries such as industrial lifting, stage lifting, energy wind power, and logistics assembly. It also provides intelligent solutions and mature supporting products, deeply cultivating the global market.
Huaige Group has successively obtained the national industrial product production license for manual hoists, obtained the export product quality license, and successfully obtained multiple honors such as ISO9001 quality management system certification and China's self operated import and export rights production enterprise.
Tomorrow's Huaige will be built into a development enterprise with modern equipment, scientific management, stable products, and networked operations
